| Brand Name : | BAIWAY |
| Model Number : | TF03K |
| Certification : | CE / FCC / RoHS |
| Price : | $27-48/set (Retail price) |
| Payment Terms : | T/T |
| Supply Ability : | 1000 pcs / month |
| Delivery Time : | 5-14 days |
Featuring an energy-saving 2.8-inch black-and-white dot-matrix large screen, it clearly displays battery level indicators and percentages. Even in complex lighting conditions in warehouses or during quick glances by drivers, the remaining battery and operational status can be easily read, significantly enhancing operational safety.
Designed with low power consumption, the standby and operational power usage is extremely minimal. Its impact on the vehicle’s battery is almost negligible, ensuring that the added display does not impose any additional burden on the forklift’s battery life.
Equipped with a low-capacity alarm, the display will issue a prominent alert via buzzer sound when the battery level drops below a preset safety threshold (e.g., 20Ah or 30Ah). This proactively reminds drivers to recharge in time, effectively preventing over-discharging of the battery, extending battery lifespan, and avoiding operational interruptions.
With 8 levels of brightness adjustment, it perfectly adapts to different lighting conditions, from bright outdoor environments to dimly lit warehouses. It eliminates glare during the day and avoids eye strain at night, consistently providing the most comfortable visual experience and reducing driver fatigue.
The front of the product offers dust and water resistance, preventing dust ingress and withstanding splashes from the front. This makes it suitable for industrial environments, effortlessly handling dust, humidity, and occasional water splashes during cleaning, ensuring excellent durability.
| Parameter | Min. | Nominal | Max. | Unit |
|---|---|---|---|---|
| Working voltage | 8.0 | 120.0 | V | |
| Working consumption | 8.0 | 12.0 | mA | |
Standby consumption | 1.0 | 2.0 | mA | |
| Power off consumption | 50.0 | μA | ||
| Accuracy of collecting voltage | ±1.0 | % | ||
| Accuracy of collecting current | ±1.0 | % | ||
| Accuracy of collecting capacity | ±1.0 | % | ||
| Capacity detection range | 0.1 | 9999.0 | Ah | |
| 50A shunt current | 0.0 | 50.0 | 75.0 | A |
| 100A shunt current | 0.0 | 100.0 | 150.0 | A |
| 350A shunt current | 0.0 | 350.0 | 500.0 | A |
| 500A shunt current | 0.0 | 500.0 | 750.0 | A |
| Ambient temperature range | -10.0 | 25.0 | 50.0 | ℃ |
| Dimensions | 100*61*17 | mm | ||
| Complete set weight (50A/100A/350A/500A) | 210/270/420/700 | g |
Battery monitors can be used in any scenario involving battery packs. They continuously track the status of the battery pack and display key parameters such as remaining charge, current voltage, current, power, and other relevant data. This allows users to monitor battery health in real time, helping to protect the battery and extend its lifespan.
It is compatible with mainstream battery types on the market, such as lead-acid batteries, lithium-ion batteries, lithium iron phosphate batteries, sodium batteries, etc.
We provide a one-year warranty period. After one year, if the product is damaged due to its own quality issues, we will continue to offer repair or replacement services based on the specific circumstances. For cases where returns or exchanges are not possible due to reasons such as shipping costs, replacements will be sent with the next order.
